Frames / S & M - ATF Frame

S & M - ATF Frame

This is the base model most of S&M's pro signature frames have started from for awhile now. It’s also the basic custom frame most of the employees there ride. It’s a little stronger and heavier than some of the frames on the market but it’s what people that really ride want. Stylish, classic, and burly all rolled up into one.

Specs:

- Rear End Length: 20" - 13.4″-13.875″
- Head Tube Angle: 20" - 75°
- Head Tube Style: Integrated (45°/45°, 41.8mm)
- Seat Tube Angle: 71°
- Seat Clamp: Integrated
- Seat Post Size: 1″ (25.4mm)
- BB Height: 20" - 11.7"
- BB Style: Mid w/EZ-out punch slots
- Standover Height: 8.5″
- Brake Mounts: Thread-On 990 (Mounts sold separately)
- Dropouts: 14mm Slot, 4Q-Baked
- Gyro Tabs: None
- Tube Set: Butted True Temper SuperTherm Tubing
- Weight: 20" - 2.12kg


** LOW STOCK **

$1399.00

Or 6 weekly payments of $233.17 with
